The
ultra light weight (.7 lbs.) aluminum alloy cylinders are suitable
for dual purpose brake and clutch applications. The full
stroke is 1" with a 3/8- 24 outlet and a 7/16-20 inlet.
The 2 mounting flange holes are on 2.5" centers, which is
standard for both AP and Girling units. The push rod length
is 4.53" with a 5/16-24 thread.
CP2623
Remote Alloy Master Cylinder
Part
No.
Size
Price
JH-2102-CP2623-625
5/8
Bore
$139.95
JH-2102-CP2623-700
.70
Bore
139.95
JH-2102-CP2623-750
3/4
Bore
139.95
AP
REMOTE RESERVOIRS
The
master cylinder reservoirs have a 7/16-20 thread and will
screw directly into the AP master cylinders.
Part No.
Dia.
Height
Price
JH-2500-CP2293-68
2.60"
4.53"
$34.95
JH-2500-CP2293-143
2.60"
4.53"
34.95
JH-2500-CP2709-15
1.75"
3.50"
44.95
CP2709-15
CP2293-68
CP2293-143
AP MASTER CYLINDER REBUILD KITS
In
the kits listed below is everything you will need to get your AP
or Girling master cylinders repaired to its as new condition.
